ASME SA213 T22 High Frequency Welded Serrated Finned Tubes Superior Heat Transfer For Heaters Industrial

Name: ASME SA213 T22 High Frequency Welded Serrated Finned Tubes Superior Heat Transfer For Heaters Industrial
Brand: YUHONG
Price: 1 USD

ASME SA213 T22 High Frequency Welded Serrated Finned Tubes Superior Heat Transfer For Heaters Industrial Manufactures

Brand Name : YUHONG

Model Number : ASME SA213 T22

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Place of Origin : CHINA

MOQ : 100 KGS

Price : Negotiate

Payment Terms : T/T,L/C

Supply Ability : 4150 Ton Per Month

Delivery Time : 20-80 days

Packaging Details : Plywooden case with Iron Frame

Product name : HFW Wound Finned Tube

Tube Material Grade : TP304, 316L, 321, SA179, T5, T9, T11, T12, T22

Material : Carbon Steel, Stainless Steel, Alloy Steel

Application : Heat Exchangers, Air Coolers, Condensers, Evaporators, Radiators

Fin material : CS, SS

Fin Spacing : 2.0mm-20mm

Wall Thickness : 0.8-3mm

Tube Diameter : 32mm, 38mm, 42mm,60.3mm,88.9mm

Contact Now

ASME SA213 T22 High-Frequency Welded Serrated Finned Tubes – Superior Heat Transfer for Heaters & Industrial Applications

Product: High-Frequency Welded Serrated Finned Tubes (ASME SA213 T22)

Material & Design:

Base Tube: ASTM A213 T22 alloy steel (high-temperature resistant).
Fin Type: Serrated (increased surface area for 30%+ heat transfer efficiency vs. smooth fins)

3

5

.
Length: 12 meters (customizable).

Key Advantages:
Enhanced Heat Transfer: Serrated fins disrupt boundary layers, optimizing thermal exchange.
Durable Welding: High-frequency welding ensures 95%+ weld ratio and low contact resistance.
Mechanical Strength: Tensile strength ≥415 MPa, yield strength ≥205 MPa (ideal for high-pressure systems).
Corrosion Resistance: Chromium-molybdenum alloy (Cr: 1.9–2.6%, Mo: 0.87–1.13%) resists oxidation.

Technical Data:

Parameter	Value
Base Material	ASTM A213 T22
Fin Height	Up to 15mm (standard)
Max Temperature	700°C
Pressure Rating	200+ MPa (welded joints)

Applications:

Heat Exchangers & Boilers: Efficient energy recovery in power plants.
Petrochemical: Heaters, condensers, and flue gas systems.
Industrial Drying: Food, pharmaceuticals, and textiles.

FAQ:
Q: Can you customize fin density?
A: Yes, we tailor fin pitch (3–10 fins/inch) per application needs.

Q: What’s the lead time?
A: 15–30 days for standard sizes; expedited options available.

With 20+ years of expertise, Yuhong Holding Group is a leading manufacturer of high-performance finned tubes, exporting to 80+ countries and ranking among China’s top 5 finned tube exporters. Equipped with 55 production lines, 20,000㎡ facility, and cutting-edge technology, we deliver unmatched quality and service.

Why Choose Yuhong?

Global Trust: 80+ countries served.
Quality Assurance: ISO-certified production with 100% testing.
End-to-End Support: From design to after-sales service.

(keywords: "serrated finned tubes," "ASME SA213 T22," "heat exchanger tubes")
